Using the Spanning Tree Algorithm

The Spanning Tree Algorithm can be used to detect and disable network
loops, and to provide backup links between switches, bridges or routers.
This allows the switch to interact with other bridging devices (that is, an
STA-compliant switch, bridge or router) in your network to ensure that only
one route exists between any two stations on the network. For a more
detailed description of how to use this algorithm, refer to "Spanning Tree
Algorithm" on page 4-2.
Use <TAB> or arrow keys to move. <Enter> to select.

Configuring Bridge STA

The following figure and table describe Bridge STA configuration.
Spanning Tree Configuration : Bridge STA Configuration
======================================================
Use <TAB> or arrow keys to move, <Space> to scroll options,
2-34
C
ONFIGURATION
Spanning Tree Configuration : Selection Menu
============================================
STA Bridge Configuration ...
STA Port Configuration ...
Spanning Tree Protocol
Priority
Hello Time (in seconds)
Max Age (in seconds)
Forward Delay (in seconds): 15
<APPLY>
other keys to make changes.
P
ROGRAM
<OK>
: ENABLED
: 32768
: 2
: 20
<OK> <CANCEL>
