3. Change your baud rate to 115200 bps, and press Enter to enable
download mode. From the terminal emulation program, select the file
you want to download, set the protocol to XModem, and then
initialize downloading.
Notes: 1. If you use Windows HyperTerminal, disconnect
reconnect
2. The download file should be an SMC6924MT binary file from
SMC; otherwise the agent will not accept it. The file naming
convention is:
Runtime program:
POST program:
Mainboard program:
4. After the file has been downloaded, the console screen will display
information similar to that shown below. Press "s" to start the
management interface, change the baud rate back to 19200, and press
Enter. The Logon screen will then appear.
XModem Download to DRAM buffer area 0x00200000:
Verifying image in DRAM download buffer 0x00200000... SUCCESS !
Update FlashROM Image at 0x02880000 ... SUCCESS !
(D)ownload another Image or (S)tart Application: [S] s
Change Baud Rate to 19200 and Press <ENTER>.
For details on managing the switch, refer to Chapter 2 for information on
the out-of-band console interface, or Chapter 3 for information on the
Web interface.
U F
PGRADING IRMWARE VIA THE
to enable the new baud rate.
Agent-Vx.yz,
Boot-Vx.yx, and
8051-Vx.yz
S P
ERIAL ORT
and
... SUCCESS !
A-3
