Port Priority Configuration

Inbound frames that do not have any VLAN tags are tagged with the input
port's default VLAN ID (PVID) and the Default Ingress User Priority as
shown in the following menu, and then sorted into the appropriate priority
queue at the output port. (Note that if the output port is an untagged
member of the associated VLAN, these frames are stripped of all VLAN
tags prior to transmission.)
The default priority for all ingress ports is zero. Therefore, any inbound
frames that do not have priority tags will be placed in the low priority
queue of the output port. You can use the following menu to adjust default
ingress priority for any port as shown below.
<APPLY> <OK> <CANCEL> <PREV UNIT> <NEXT UNIT> <PREV PAGE> <NEXT PAGE>
Use <TAB> or arrow keys to move, other keys to make changes.
2-54
C
ONFIGURATION
802.1P Port Priority Configuration : Unit 1 Port
==================================
Port Default Ingress
User Priority
---------------------------------------
1
2
3
4
5
6
7
8
9
10
11
12
P
ROGRAM
Number of Egress
Traffic Class
0
0
0
0
0
0
0
0
0
0
0
0
2
2
2
2
2
2
2
2
2
2
2
2
1 - 12
