802.1Q VLAN Static Table Configuration

Use this screen to create a new VLAN or modify the settings for an
existing VLAN. You can add/delete port members for a VLAN from any
unit in the stack as a tagged or untagged member. Or you can prevent a
port from being automatically added to a VLAN by the GVRP protocol.
The switch supports an overlapping VLAN feature that allows any port to
be configured as a member of multiple VLANs. This enables inter-switch
links to carry traffic from VLANs that cross the network. Also, shared
resources, such as servers, can be connected to a port that is configured as
a tagged member of multiple VLANs.
Note: Overlapping VLANs on a port connected to another device
requires that device, switch or server, including network card and
operating system, to be VLAN tag aware.
802.1Q VLAN Static Table Configuration
======================================
Unit Egress Ports
1. 111111111111 111111111111 ---- 000000000000 000000000000 ----
2. ------------ ------------ ---- ------------ ------------ ----
3. ------------ ------------ ---- ------------ ------------ ----
4. ------------ ------------ ---- ------------ ------------ ----
5. ------------ ------------ ---- ------------ ------------ ----
6. ------------ ------------ ---- ------------ ------------ ----
Unit Untagged Ports
1. 111111111111 111111111111 ----
2. ------------ ------------ ----
3. ------------ ------------ ----
4. ------------ ------------ ----
5. ------------ ------------ ----
6. ------------ ------------ ----
<APPLY>
Use <TAB> or arrow keys to move, other keys to make changes.
VID VLAN Name
------------------------------
1
<OK>
C
ONFIGURING THE
Status
Active
Forbidden Egress Ports
VID : 1
[Show]
[More]
[New]
<CANCEL>
S
WITCH
2-59
