W -B M
EB ASED ANAGEMENT
Parameter
Egress Ports
Untagged Ports

VLAN Static List

Use this screen to create or remove VLAN groups.
Parameter
Current
New
Status
Add
Remove
3-36
Description
Shows the ports which have been added to the displayed
VLAN group.
Shows the untagged VLAN port members.
Description
Lists all the current VLAN groups created for this system.
Up to 256 VLAN groups can be defined.
To allow this switch to participate in a VLAN group that
extends beyond this switch, you must add the VLAN ID for
the required external groups.
Allows you to specify the name and numeric identifier for a
new VLAN group. (The VLAN name is only used for
management on this system; it is not added to the VLAN
tag.)
Enables/disables the specified VLAN.
Adds a new VLAN group to the current list.
Removes a VLAN group from the current list.
If a removed port is no longer be assigned to any other
group as an untagged port, it will automatically be assigned
to VLAN group 1 as untagged.
