Tftp Download Management - SMC Networks TigerStack 100 1000BASE-X Management Manual

TFTP Download Management

Use the TFTP Download Management menu to load software updates
into the switch. The download file should be an SMC6924MT binary file
from SMC; otherwise the agent will not accept it. The success of the
download operation depends on the accessibility of the TFTP server and
the quality of the network connection. After downloading the new
software, the agent will automatically restart itself. Parameters shown on
this screen are indicated in the following figure and table.
Parameter
Server IP Address
Download Mode
File Name
Start TFTP Download Issues request to TFTP server to download the specified
Description
IP address of a TFTP server.
The system downloads to permanent flash ROM.
The SMC6924MT binary file to download.
file.
F U
IRMWARE PGRADE
O
PTIONS
3-17
