Using a Mirror Port for Analysis

You can mirror traffic from any source port to a target port for real-time
analysis. You can then attach a logic analyzer or RMON probe to the target
port and study the traffic crossing the source port in a completely
unobtrusive manner. When mirroring port traffic, note that the target port
must be included in the same VLAN as the source port. (See "Configuring
Virtual LANs" on page 2-56.)
You can use the Mirror Port Configuration screen to designate a single
port pair for mirroring as shown below.
<APPLY>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter
Mirror Source Port
Mirror Target Port
Status
2-44
C
ONFIGURATION
Mirror Port Configuration
=========================
Mirror Source Port : Unit 1
Mirror Target Port : Unit 1
Status
Description
The port whose traffic will be monitored.
The port that will duplicate or "mirror" all the traffic
happening on the monitored port.
Enables or disables the mirror function.
P
ROGRAM
Port 1
Port 2
: DISABLED
<OK> <CANCEL>
