Viewing the Current Spanning Tree Information

The Spanning Tree Information screen displays a summary of the STA
information for the overall bridge or for a specific port. To make any
changes to the parameters for the Spanning Tree, use the Spanning Tree

Configuration menu.

Use <TAB> or arrow keys to move. <Enter> to select.

Displaying the Current Bridge STA

The parameters shown in the following figure and table describe the
current Bridge STA Information.
Priority
Hello Time (in seconds)
Max Age (in seconds)
Forward Delay (in seconds): 5
Hold Time (in seconds)
Designated Root
Root Cost
Root Port
Reconfig Counts
Topology Up Time
Use <Tab> or arrow keys to move, <Enter> to select.
Spanning Tree Information : Selection Menu
==========================================
STA Bridge Information
STA Port Information ...
Spanning Tree Information : Bridge STA Information
==================================================
...
<OK>
: 32768
: 2
: 20
: 1
: 128.0000E800E800
: 501
: 1
: 3
: 48069 (0 day, 1 hr, 2min, 34 sec)
<OK>
C
ONFIGURING THE
S
WITCH
2-39
