U S
SING THE YSTEM
Menu
TFTP Download
Configuration Save
& Restore

Changing the Network Configuration

Use the Network Configuration menu to set the bootup option, configure
the switch's Internet Protocol (IP) parameters, enable the on-board Web
agent, or to set the number of concurrent Telnet sessions allowed. The
screen shown below is described in the following table.
<APPLY>
Use <TAB> or arrow keys to move. <Enter> to select.
Parameter
IP Configuration
IP Connectivity Test (Ping)
HTTP Configuration
MAX Number of Allowed
Telnet Sessions
MAC Address
2-12
C
ONFIGURATION
Description
Downloads new version of firmware to update
your system (in-band).
Saves the switch configuration to a file on a TFTP
server. This file can be later downloaded to
restore the configuration.
Network Configuration
=====================
IP Configuration ...
IP Connectivity Test (Ping) ...
HTTP Configuration ...
MAX Number of allowed Telnet sessions (1 -4) : 4
MAC Address : 00-E0-29-52-28-00
Description
Screen used to set the bootup option, or
configure the switch's IP parameters.
Screen used to test IP connectivity to a specified
device.
Screen used to enable the Web agent.
The maximum number of Telnet sessions allowed
to simultaneously access the agent module.
Physical address of the agent module.
P
ROGRAM
<OK> <CANCEL>
