Displaying the IP Multicast Registration Table

Use the IP Multicast Registration Table to display all the multicast groups
active on this switch, including multicast IP addresses and the
corresponding VLAN ID.
VID Multicast IP
--------------------------------------------------------------------
1 225.1.1.1
Sorted by
VID
Multicast IP :
[Show]
Use <TAB> or arrow keys to move, <Enter> to select.
Menu
VID
Multicast IP
Unit
Dynamic Port Lists
Learned by
Sorted by
[Show]
[More]
IP Multicast Registration Table
===============================
Unit Multicast Group Port Lists
1. 000000001100 110000000000 00
2. 000000001100 110000000000 00
3. 000000001100 110000000000 00
4. 000000001100 110000000000 00
5. 000000001100 110000000000 00
6. 000000001100 110000000000 00
: VID + Multicast IP
: 1
[More]
<OK>
Description
VLAN ID assigned to this multicast group.
IP address for specific multicast services.
Stack unit.
The switch ports registered for the indicated multicast
service.
Indicates the manner in which this address was learned:
Dynamic or IGMP.
Selects the primary sort key for displaying table entries.
Note that only VID+Multicast IP is implemented in the
current firmware release.
Displays the address table sorted on VID and then
Multicast IP.
Scrolls through the entries in the address table.
M
ONITORING THE
Learned by
IGMP
IGMP
IGMP
IGMP
IGMP
IGMP
S
WITCH
2-73
