Viewing the Current Port Configuration

The Port Information screen displays the port type, status, link state, and
flow control in use, as well as the communication speed and duplex mode.
To change any of the port settings, use the Port Configuration menu.
Port
----------------------------------------------------------------
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
<APPLY> <OK> <CANCEL> <PREV UNIT> <NEXT UNIT> <PREV PAGE> <NEXT PAGE>
Use <TAB> or arrow keys to move. <Enter> to select.
Parameter
Type
Operational
Link
2-32
C
ONFIGURATION
Port Information : Unit 1 Port
================
Type Operational
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
100FX YES
Description
Shows port type as:
100FX
1000SX
1000LX
1000T
Shows if the port is functioning or not.
Indicates if the port has a valid connection to an
external device.
P
ROGRAM
Link FlowControl
InUse
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
UP NONE
: 100BASE-FX
: 1000BASE-SX
: 1000BASE-LX
: 1000BASE-T
1 - 12
Speed and
Duplex InUse
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
100-FULL
