P Port Traffic Class Information - SMC Networks TigerStack 100 1000BASE-X Management Manual

Parameter
Port
Default Ingress User
Priority
Number of Egress Traffic
Classes

802.1p Port Traffic Class Information

This switch provides two priority levels with Weighted Fair Queuing for
port egress. This means that any frames with a priority tag from 0~3 are
sent to the low priority queue "0" while those from 4~7 are sent to the
high priority queue "1" as shown in the following screen.
802.1P Port Traffic Class Information :
=====================================
Port
-------------------------------------
1
2
3
4
5
6
7
8
9
10
11
12
<APPLY> <OK> <CANCEL> <PREV UNIT> <NEXT UNIT> <PREV PAGE> <NEXT PAGE>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter
Port
User Priority
Description
Numeric identifier for switch port.
Default ingress priority can be set to any value from
0~7, where 0~3 specifies the low priority queue and
4~7 specifies the high priority queue.
Indicates that this switch supports two priority output
queues.
User Priority
0 1 2 3
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
Description
Numeric identifier for switch port.
Shows that user priorities 0~3 specify the low priority
queue and 4~7 specify the high priority queue.
C
ONFIGURING THE
Unit 1 Port
4 5 6 7
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
1 1 1 1
S
WITCH
1 - 12
2-55
