Configuring Bridge MIB Extensions

The Bridge MIB includes extensions for managed devices that support
Traffic Classes and Virtual LANs. To display and configure these
extensions, use the Extended Bridge Configuration screen as shown below.
<APPLY>
Use <TAB> or arrow keys to move. <Space> to scroll option.
Parameter
Bridge Capability
Extended Multicast
Filtering Services
Traffic Classes
Static Entry Individual
Port
VLAN Learning
Extended Bridge Configuration
=============================
Bridge Capability : (Read Only)
Extended Multicast Filtering Services : NO
Traffic Classes
Static Entry Individual Port
VLAN Learning
Configurable PVID Tagging
Local VLAN Capable
Bridge Settings :
Traffic Class : TRUE
GMRP
GVRP
Description
This switch does not support filtering of individual
multicast addresses based on GMRP (GARP Multicast
Registration Protocol).
This switch provides mapping of user priorities to
multiple traffic classes. (Refer to "802.1p Port Traffic
Class Information" on page 2-55.)
This switch allows static filtering for unicast and
multicast addresses. (Refer to Network Monitor Menu
/ Static Unicast Address Table Configuration and Static
Multicast Address Table Configuration.)
This switch uses Shared VLAN Learning (SVL),
whereby the VLAN filtering database is shared among
all ports.
C
: DISABLED
: DISABLED
<OK>
ONFIGURING THE
: YES
: YES
: SVL
: YES
: NO
<CANCEL>
S
WITCH
2-51
