Parameter
VID
VLAN Name
Status
Unit
Egress Ports
Forbidden Egress Ports
Untagged Ports
[Show]
[More]
[New]
2-60
C
ONFIGURATION
Description
The ID for the VLAN currently displayed.
Range: 1-2048
A user-specified symbolic name for this VLAN.
String length: Up to 8 alphanumeric characters
Sets the current editing status for this VLAN as: Not in
Service, Destroy or Active.
Stack unit.
Set the entry for any port in this field to "1" to add it to
the displayed VLAN, or "0" to remove it from the
VLAN.
Prevents a port from being automatically added to this
VLAN via GVRP. Note that GVRP is not supported in
the current firmware release.
You can add a port to the displayed VLAN as an
untagged port by setting this field to "1" or as a tagged
port by setting it to "0." This field is only enabled if the
corresponding port has been added to the displayed
VLAN as an "Egress Port."
Displays settings for the specified VLAN.
Displays consecutively numbered VLANs.
Sets up the screen for configuring a new VLAN.
