Displaying RMON Statistics

Use the RMON Statistics screen to display key statistics for each port from
RMON group 1. (RMON groups 2, 3 and 9 can only be accessed using
SNMP management software such as EliteView.) The following screen
displays the overall statistics on traffic passing through each port. RMON
statistics provide access to a broad range of statistics, including a total
count of different frame types and sizes passing through each port. Values
displayed have been accumulated since the last system reboot.
Drop Events
Received Bytes
Received Frames
Broadcast Frames
Multicast Frames
CRC/Alignment Errors :0
Undersize Frames
Oversize Frames
Fragments
[Refresh Statistics]
[Reset Counters]
<OK>
Use <TAB> or arrow keys to move. <Enter> to select.
Menu
Drop Events
Received Bytes
Received Frames
Broadcast Frames
RMON Statistics : Unit 1 Port
===============
:0
:199299
:15746
:3249
:0
:0
:0
:0
<PREV UNIT> <NEXT UNIT>
Description
The total number of events in which packets were
dropped due to lack of resources.
Total number of bytes of data received on the network.
This statistic can be used as a reasonable indication of
Ethernet utilization.
The total number of frames (bad, broadcast and
multicast) received.
The total number of good frames received that were
directed to the broadcast address. Note that this does
not include multicast packets.
M
ONITORING THE
Jabbers
Collisions
64 Byte Frames
65-127 Byte Frames
128_255 Byte Frames
256-511 Byte Frames
512-1023 Byte Frames
1024_1518 Byte Frames :35696
<PREV PORT>
S
WITCH
1
:0
:0
:37837
:674356
:45430
:20447
:3740
Show port : 1
[Show]
<NEXT PORT>
