Saving the System Configuration

Use the Configuration Save & Restore menu to save the switch
configuration settings to a file on a TFTP server. The file can be later
downloaded to the switch to restore the switch's settings. The success of
the operation depends on the accessibility of the TFTP server and the
quality of the network connection. Parameters shown on this screen are
indicated in the following figure and table.
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter
Configuration Upload
Upload Server IP
Upload Filename
[Process TFTP Upload]
Upload Status
Upload Server IP
Upload Filename
[Process TFTP Upload]
Upload status
Download Server IP
Download Filename
[Process TFTP Download]
Download status : Complete
<APPLY>
Description
IP address of a TFTP server.
The name of the file to contain the switch
configuration settings.
Issues a request to upload the configuration settings
to the specified file on the TFTP server.
Indicates if an upload is "Complete" or "In
Progress."
M
ANAGEMENT
Configuration Upload
====================
: Complete
Configuration Download
======================
<OK>
S
ETUP
:
:
:
:
<CANCEL>
M
ENU
2-25
