SMC Networks TigerStack 100 1000BASE-X Management Manual page 76

U S
SING THE YSTEM
Parameter
Creation Time
Status
Unit
Current Egress Ports
Current Untagged Ports
Sorted by VID
[Show]
[More]
2-58
C
ONFIGURATION
Description
The value of sysUpTime (System Up Time) when this
VLAN was created.
Shows how this VLAN was added to the switch.
Dynamic GVRP: Automatically learned via GVRP.
Permanent: Added as a static entry.
Stack unit.
Shows the ports which have been added to the
displayed VLAN group, where "1" indicates that a port
is a member and "0" that it is not.
If a port has been added to the displayed VLAN (see
Current Egress Ports), its entry in this field will be "1"
if the port is untagged or "0" if tagged.
The VLAN ID number from which the display will
start.
Displays the members for the VLAN indicated by the
"Sorted by VID" field.
Displays any subsequent VLANs if configured.
P
ROGRAM
