4.5.2 Drive Shaft for Cell Cultures

28 March 2018
1 Centring plate of drive shaft
Stirrers for bacterial cultures in 1400 mL vessels are equipped with
four magnets as well as a centring plate.
1
1 Magnet holder
2 Magnet
The illustration on the left shows the lower section of a drive shaft
for cell cultures with a magnet holder and two magnets. In contrast
to the drive shaft for bacterial cultures, this drive shaft is not an-
chored in a bearing.
1
2
