9.5.1 Dismantling the used Ball Bearings

Procedure
28 March 2018
To dismantle the used ball bearings proceed as follows:
1. Remove the vessel top plate from the vessel and carefully put
it top side down.
Avoid any stress or knocks on the stirrer shaft!
2. Dismantle the sparger.
3. Carefully push the O-ring out of the groove on the inside of the
bearing holder.
Do not use sharp tools!
