Multifors 2 - Parallel Bench-top Bioreactor
Preparations for Use
Procedure
Page 120 of 211
3. Hook in the threaded bolt.
4. Close the clamping ring.
Securing the vessel on the basic unit
To secure the vessel(s) in the vessel holder and transport frame on
the basic unit, proceed as follows:
1. Insert the vessel in the vessel holder and transport frame.
2. Hold the vessel holder and transport frame using the grips on
either side and place it onto the thermal blocks from above.
3. Hold both clamps of the snap closure between the thermal
blocks, pressing the left-hand clamp inwards at the same time.
The clamps are released; the vessel retaining brackets on the
basic unit are engaged.
NOTICE!
Do not pull the right-hand clamp forwards!
