3.2 Dimensions Culture Vessels and Vessel Holder

Dimensions
A
B
C
D
28 March 2018
Side View
Depending upon height of the culture vessels, the height of the
frame which houses them is adjustable.
Vessels, Total volume
0,4 l Bact./Cell 0,70 l Cell
182 mm 196 mm
260 mm 274 mm
350 mm 364 mm
395 mm 409 mm
Multifors 2 - Parallel Bench-top Bioreactor
0,75 l Bact. 1,0 l Cell
196 mm 182 mm
274 mm 260 mm
364 mm 350 mm
409 mm 395 mm
Technical Data
1,4 l Bact.
222 mm
300 mm
390 mm
435 mm
