9.5.2 Mounting the new Ball Bearings

28 March 2018
10. Pull the lower ball bearing off the stirrer shaft.
CAUTION!
Risk of damaging the ball bearings due to inap-
propriate mounting!
The ball bearings are damaged and will therefore
be unusable, if they are inappropriately mounted or
have an incorrect axial loading.
Therefore:
– Mount the ball bearings carefully and with the
correct orientation.
– Do not put pressure on the wrong side of the
ball bearings!
– Strictly follow the mounting procedure described
here.
Before mounting the new ball bearings, note the following:
The ball bearings only allow a one-sided axial load. It is absolutely
necessary that they have the correct orientation when mounting.
The difference between both sides of the ball bearing is visible as
follows:
