Multifors 2 - Parallel Bench-top Bioreactor
Preparations for Use
Page 126 of 211
Antifoam sensor with clamping adapter 10 mm ports
a) Loosen the screw next to the blanking plug in the 10 mm
port with a screw driver (no. 3) and remove it.
b) Pull out and remove the blanking plug from the port.
Antifoam sensor with clamping adapter 12 mm ports
a) Loosen and remove the blanking plug from the 12 mm
port using the hexagon socket spanner provided with the
equipment.
4.
Carefully insert the antifoam sensor into the vessel top plate
port.
5. Fixate the antifoam sensor in the port:
Antifoam sensor with clamping adapter 10 mm ports
a) Screw in the screw with the screw driver and insert the
antifoam sensor to its fitting at the same time.
Ensure that the screw head is positioned in the gap be-
tween clamping adapter and the port fitting of the sensor.
b) Only tighten the screw lightly.
NOTICE!
The screw has no sealing function and therefore,
does not have to be screwed in too tightly to facili-
tate loosening for cleaning later.
