4.2.2 Operating Panel Connections

1
1 USB2.0 x 2: for backups and service pur-
poses
1
2 Ethernet: for Ethernet cable
network.
3 COM2 (Reserve)
28 March 2018
NOTICE!
The ON/OFF key is locked when a bioreactor (fer-
mentation) is running. A dialogue box with the ap-
propriate message appears when pressing the
ON/OFF key by mistake during fermentation. When
pressing the ON/OFF key when the bioreactor (fer-
mentation) is stopped, a dialogue box for shutting
down the system appears
Five connectors labelled with different symbols are situated on the
rear side of the operating panel.
2
3
to connect with a
1
Multifors 2 - Parallel Bench-top Bioreactor
Setup and Function
4
4 COM1: for iDDC bus cable
5 DC: for power supply cable
5
(display cable)
1
1
