Pumps - Infors HT Multifors 2 Operating Manual

Multifors 2 - Parallel Bench-top Bioreactor
Technical Data

3.5.11 Pumps

Page 40 of 211
NOTICE!
Details about technical data, use and maintenance
of the sensors are in the separate documentation
from the sensor manufacturers.
Description Value
Type Peristaltic
Standard Digital
(3 pieces)
Analogue
(1 piece)
Option 1 or several free-standing pumps, analogue
Rotation speed Digital
Analogue
Accuracy ± 1 % FS
Pump hoses & flow rates
Description Value
Material PharMed BPT
Standard iD: 1.0 mm
Wall thickness: 1.1 mm
Flow rate: 3.5 ml min
Option 1 iD: 0.5 mm
Wall thickness: 1.15 mm
Flow rate: 1.2 ml min
Option 2 iD: 2.5 mm
Wall thickness: 1,0 mm
Flow rate: 17.2 ml min
Flow rates All flow rates at 74 min
Acid
Base
AF = Antifoam
Feed
74 min / fixed rotation speed
-1
74 min / max. rotation speed,
-1
adjustable within range of 0 % up
to 100 %
-1
-1
-1
-1 (100 % rotation speed)
28 March 2018
