Remote Control - Polycom RealPresence Group Series Reference Manual

Remote Control

This section provides information about the IR signals for RealPresence Group Series systems.
Note: This information is provided for reference only. Polycom claims no
responsibility or liability for programmed third-party remote control devices.
Notes
● Wake up – 2.6 ms on; 2.6 ms off.
● 0–559 µs (22 pulses at 38 KHz) on; 845 µs (33 pulses at 38 KHz) off.
● 1–845 µs (33 pulses at 38 KHz) on; 1192 µs (46 pulses at 38 KHz) off.
● EOM–559 µs (22 pulses at 38 KHz) on.
● System Code consists of a User ID field (upper nibble) and the Polycom Vender Code (lower nibble)
with value 0x5. The default User ID value is 0x3, so the default System Code value is 00110101 or
0x35.
● Parity is a 2-bit field consisting of a parity bit (b1) and a toggle bit (b0). Parity is even.
● Inter-burst timing is 2200 pulse times at 38.062 KHz or 57.8 ms.
● 38.062 KHz signal is at 1/3 duty cycle to LED.
● Multi-bit fields are transmitted most significant bit first.
● Bits are labeled b0..bn, where b0 is the least significant bit.
Protocol is: <Wake up> + <System Code> + <Key Code> + <Parity> + <EOM>
Key Name
#
*
0
1
2
3
4
5
6
7
8
9
Auto
Polycom, Inc.
Key Code Key Code
1100 0CH
1011 0BH
110000 30H
110001 31H
110010 32H
110011 33H
110100 34H
110101 35H
110110 36H
110111 37H
111000 38H
111001 39H
11001 19H
Polycom RealPresence Group Series Specifications
Parity
Even
Odd
Even
Odd
Odd
Even
Odd
Even
Even
Odd
Odd
Even
Odd
