Polycom RealPresence Group Series Setup Sheet

Polycom RealPresence
®
with 65 Inch Dual Displays
This supplement describes how to attach 65 inch dual displays on the Polycom
Media Center. Follow the instructions in Setting Up the Polycom RealPresence Group Series Media Center,
1725-08510-00X, and use this supplement to replace the steps to install the displays.
Single 55/65 inch Lower Display Rail, 1354-67626-002
(2) Dual 65 inch Lower Display Rail Extension, 1354-68667-002
Dual 65 inch Center Top Display Rail, 1354-68669-001
(2) Dual 65 inch Upper Display Rail Extension, 1354-68671-001
For more information about the components of the RealPresence Group Series Media Center,
refer to the documentation at
http://support.polycom.com/PolycomService/support/us/support/video/group_series/group_packaged_solutions.html.
The Media Center components are heavy. Polycom recommends that two people perform the installation.
© 2018, Polycom, Inc. All rights reserved. POLYCOM® and the names and marks associated with Polycom's products are trademarks and/or service marks of
Polycom, Inc. and are registered and/or common law marks in the United States and various other countries. No portion hereof may be reproduced
or transmitted in any form or by any means, for any purpose other than the recipient's personal use, without the express written permission of Polycom.
Group Series Media Center
®
www.polycom.com
1725-68117-002B
® ®
RealPresence Group Series
(4) Display Mounting Bracket
Assembly
2342-67629-001
(4) M8 x 20 Button Head Cap Screw
1601-52713-001
(4) M8 Hex Flange Nut
1600-52845-001
(4) M10 x 25 Flanged Socket Head
Cap Screw
1601-67617-002
M8 Wrench
1102-68064-001
SETUP SHEET
