Polycom RealPresence Group Series Reference Manual page 27

Connect a Polycom EagleEye III Camera to a Polycom RealPresence Group 700 System a
Second Camera (Option 2):
Use Polycom Power Supply Only
Polycom EagleEye IV Camera as the Main Camera
You can connect a Polycom EagleEye IV camera (part number 1624-66057-001 or 1624-66061-001) to a
RealPresence Group system as the main camera.
Option 1
● HDCI Polycom EagleEye IV Digital Camera Cable
● Power supply. Power supply is required only if you want to use the IR remote to wake the system
when it is in sleep mode on RealPresence Group 700 systems. Use only the approved power supply
from Polycom (part number 1465-52748-040). Do not exceed 12 Volts at 3 Amps. Verify the polarity
of the power supply as shown on the Polycom camera next to the power supply input.
Polycom, Inc.
1
100-240VAC 50/60Hz 2.3A
DC IN 12V
Part Number: 1465-52748-040
4
2 3
A
C
B
Optional, up to 100 ft
Room Integration
1 2 3
A
36
