3.5.5 How to set the Multicator Receiver Configuration

1. Log into the browser interface of the appliance.
2. Click the Configuration link; Click the Multicator link.
3. Click the enable radio button in the "Enable Multicast Receiver" field in the "Multicator Receiver"
section.
4. Enter the controller port of the Multicator controller. Default: 4929
5. In the "FTP Server" field, enter the IP address of the FTP server that will receive the file delivered to
the receiver via multicast.
6. In the "FTP User" field, enter the user name for the FTP server that will receive the file delivered to
the receiver via multicast.
7. Default: anonymous
8. In the "FTP Password" field, enter the password for the FTP server where the file received via
multicast will be placed.
9. Default: no directory, file deposited in FTP root
10. In the "FTP Directory" field, enter the directory on the FTP server where the file received via multicast
will be placed.
11. In the "FTP Retries" field select the number of times the receiver should attempt to deliver a file to
the FTP server before abandoning the file transfer. Default: 5
12. In the "FTP seconds between retries" field select the number of second between FTP retry attempts.
Default: 10
13. In the "Action on FTP failure" field, select the action to be taken on the file if the file transfer fails and
all retry attempts have been exhausted. Default: Keep.
