Interface C: (Ethernet1/0)
FX subnet
Service group 99
This should be defined to handle redirected outbound requests from the users destined for the
subnets on Interface B. "Interface C" must be excluded from this to avoid loop-backs that would
otherwise occur when FXs spoof the user IP addresses.
Service group 96
Should be defined to handle redirected responses from content servers that would have
otherwise been sent out on "Interface-A".
The subnets:
A: User (192.168.103.xxx subnet)
B: Content servers - all other subnets via gateway at 192.168.101.158
C: FXs (192.168.106.xxx)
#show running-config
Building configuration...
Current configuration: 948 bytes
!
version 12.2
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname 2600-lab
!
enable password xxxx
!
memory-size iomem 10
ip subnet-zero
ip wccp 96
ip wccp 99
!
!
no ip domain-lookup
ip domain-name example.enterprise.com
ip name-server 192.168.101.202
!
!
interface Ethernet0/0
ip address 192.168.103.224 255.255.255.0
ip wccp 96 redirect out
half-duplex
!
interface Ethernet0/1
ip address 192.168.101.224 255.255.255.0
ip wccp 99 redirect out
half-duplex
!
interface Ethernet1/0
ip address 192.168.106.224 255.255.255.0
