Traffic Interfaces
In-Path Interfaces
Configure In-Path Interfaces for user data.
LAN Interfaces
Set speed, MTU and VLAN options of the physical LAN interfaces. .
Port Definitions
Configure a list of port definitions.
WCCP Settings
The Web Cache Communication Protocol (WCCP) is a Cisco-developed content-routing
technology which allows you to integrate cache engines into your network infrastructure.
Quality of Service Settings
Hierarchy
This screen delineates the configured relationship of Queues, Groups and Links.
Links
Maintain QoS links. Links correspond to a satellite modems.
Groups
Maintain QoS groups which allow you to group multiple QoS queues.
Group Filters
Maintain rules which classify traffic and assign it to one of the QoS groups.
Queues
Maintain QoS Queue definitions.
Queue Filters
Maintain rules which classify traffic and assign it to one of the QoS queues.
NOTE: The screens that have specific functionality for the FX Series ADCs or the FX Series Remotes can be
found in these sections in this manual:
FX Series ADC Specific Settings Section
General Settings
FX Series Remote Specific Settings Section.
General Settings
