 "Overflow – memory" - The FX is low in memory resources. WANOP will continue for existing
accelerated connections, however new connections from clients will be forwarded directly to the
content servers.

"Overflow – sessions" - The FX has reached its specified limit for the number of concurrent
accelerated connections. WANOP will continue for existing accelerated connections, however
new connections from clients will be forwarded directly to the content servers.

"Overflow - active flows" - The FX has reached its limit of active flows. If in 'in-line'
traffic interception mode, the FX will go into 'bypass'. If in 'WCCP' traffic interception
mode 'the FX will drop out of all WCCP service groups.
Server running since
This is the date and time that the FX Series ADC was last started.
Refresh interval (sec)
This is how often the WANOP monitor will refresh the statistics. Changes take effect immediately and are
remembered in subsequent accesses to the WANOP monitor.
Action Buttons
Detailed Stats:
This displays all aggregate tallies accumulated since the ADC service was last started or since they were
last reset.
Connections:
This displays a list of each connection-group. If the ADC is accelerating traffic for FX-Remotes then a
connection group may be comprised of multiple TCP connections that form a TurboStream. If the ADC is
servicing HTTP clients in a one-sided mode then each connection group will be comprised of a single TCP
connection. When the list is displayed you can drill down on an individual connection-group to examine
detailed tallies.
Port stats:
Displays traffic statistics for each port definition that has been configured.
Reset Stats:
This button clears the acceleration server tallies and other stats.
Clear Cache:
This clears all objects out of all caches and then restarts the acceleration service.
