Data Rate:
This gives the configured data rate for the link. If the modem is configured for ACM, this will indicate
the rate that is read from the modem.
Group Level 1
Filter:
This is a list of all filters defined to get to the group immediately to the right in the table. It is also a
hyper link that will take you to the group filter page. There are two basic ways to add a filter. One is
to navigate to the Configuration\Quality of Service\Group Filters page and select the add button. The
other is to navigate to Configuration\Quality of Service\Group Filters\Add.
Name:
This is the name given to the group. There are two basic ways to add a group. One is to navigate to
the Configuration\Quality of Service\Group page and select the add button. The other is to navigate
to Configuration\Quality of Service\Group\Add. The name is a hyper link that group's configuration
page. At each level, there is a default group. This is the group where traffic that is not otherwise
selected by a filter will go. This group by default will have the name "Default". This name can
changed and another group can be selected as the default. The default queue will be designated by
the asterisk "*" appended to the name.
CIR:
This is the Committed Information Rate of the group. Setting this to a number higher than the
configured Link rate will result in an error.
MIR:
This is the Maximum Information Rate of the group.
Group Level 2
Filter:
This is a list of all filters defined to get to the group immediately to the right in the table. It is also a
hyper link that will take you to the group filter page. There are two basic ways to add a filter. One is
to navigate to the Configuration\Quality of Service\Group Filters page and select the add button. The
other is to navigate to Configuration\Quality of Service\Group Filters\Add.
Name:
This is the name given to the group. There are two basic ways to add a group. One is to navigate to
the Configuration\Quality of Service\Group page and select the add button. The other is to navigate
to Configuration\Quality of Service\Group\Add. The name is a hyper link that group's configuration
page. At each level, there is a default group. This is the group where traffic that is not otherwise
selected by a filter will go. This group by default will have the name "Default". This name can
changed and another group can be selected as the default. The default queue will be designated by
the asterisk "*" appended to the name.
CIR:
This is the Committed Information Rate of the group. Setting this to a number higher than the
configured parent rate will result in an error.
MIR:
This is the Maximum Information Rate of the group.
Queue
Filter:
This is a list of all filters defined to get to the queue immediately to the right in the table. It is also a
hyper link that will take you to the queue filter page. There are two basic ways to add a filter. One is
to navigate to the Configuration\Quality of Service\Queue Filters page and select the add button.
The other is to navigate to Configuration\Quality of Service\Queue Filters\Add.
