Comtech EF Data / Stampede
1.8.4 FX Series Hardware Specification
FX Series 1005
Model
Form Factor
Weight
Dimensions
(h x w x d)
Memory
Storage
Network Interface (GE)
Ports/Fail-to-Wire Pairs
Serial Ports
USB Interface Ports
Rack Mount Kits
Power Supply – UL Approved,
FCC Compliant
Power Supply Safety/EMC
Certifications
Environment
FX Series Administration Guide - Version 6.2.2
Chapter: Overview - FX Series
Section: FX Series Appliances Data Sheet
FX Series 1010
FX-1005
1RU
2.6 lbs. (1.2kg)
1.7" x 8.5" x 7.4"
(43 x 215 x 188 mm)
4 GB
(1) 160 GB SATA
4/1
1
2
1 or 2 units in 1RU
Requires a 60 W/12V power
adapter with lock
EN 61000/IEC 6100-
Compliant
Australian AS/NZS Class A
FCC Part 15 Subpart B
Canada ICES-003 Class A
Europe/CE Mark
ROHS
Operating temp
0 - 40°C,
Storage temp
-20 - 60°C,
Humidity 5 - 90%
Figure 1-6 FX Series Hardware Specifications
FX Series 4010
FX-1010
1RU
1RU
13.3 lbs. (6.0 kg)
15 lbs. (6.8 kg)
1.7" x 17.0" x 15.6"
1.7" x 16.8" x 14.0"
(44 x 431 x 395 mm)
(43 x 427 x 356 mm)
4 GB
16 GB
(1) 160 GB SATA
(1) 1 TB SATA III
11/0
4/1
1
1
2
2
200 W ATX power supply
Single Power
unit with input range of
(200 W)
90~264V@ 47-63 Hz
Auto (100V-240V)
EN 61000/IEC 61000-
En 60950/IEC 60950-
Compliant
Compliant
Australian AS/NZS Class A
Canada – CUL Listed
FCC Part 15 Subpart B
Germany –TUV Listed
Canada ICES-003 Class A
Europe/CE Mark
Europe/CE Mark
CCC Certified
ROHS
ROHS
Operating temp
Operating temp
0 - 40°C,
10 - 35°C,
Storage temp
Storage temp
-20 - 60°C,
-40 - 70°C,
Humidity 5 - 90%
Humidity 8 - 90%
FX-4010
41
MN-FXSERIESADM6 Rev 6
