Data Sheet Notes:
(a) When used as an ADC, the FX-1005 will handle 3000 concurrent sessions.
(b) Maximum accelerated WAN rates are a function of compressibility. If all content is being GZIP
compressed with a ratio of greater than 4:1, the maximum WAN rate may not be accelerated.
(c) The number of images handled per second is a function of image size.
(d) Available as either a stand-alone feature or part of the WAN optimization product. As a stand-
alone feature, the maximum data rate is 700 Mbps, when purchased with the WAN optimization;
the data rate is limited to the WAN optimization rate.
(e) Packets per second (PPS) is 50% outbound and 50% inbound. Header compression is currently
only available in point-to-point configurations and is not currently supported in the FX-1010.
Header Compression is currently available as either a standalone feature added to the base
configuration or part of the WAN Optimization product. When purchased without the WAN
Optimization feature the maximum rate is 700KBps. When included with WAN Optimization, the
data rate is limited to the WAN Optimization rate.

1.8.3 Configuration Models

The Base Configuration with QOS only is an option with no WAN Optimization.
Option 1 Add Header Compression (rates up to700KBps) with no WAN Optimization.
Option 2 Wan Optimization including Header Compression with rates as shown in the tables.
FX Series Administration Guide - Version 6.2.2
Chapter: Overview - FX Series
Section: FX Series Appliances Data Sheet
FX-4010-ADC
Image Size Images Per Second
10 KB 1800
50KB 1000
500KB
FX-1005-ADC
Images Per Second
80
35
100 35
40
