Name:
This is the name given to the queue. There are two basic ways to add a queue. One is to navigate to
the Configuration\Quality of Service\Queue page and select the add button. The other is to navigate
to Configuration\Quality of Service\Queue\Add. The name is a hyper link that queue's configuration
page. At each level, there is a default queue. This is the queue where traffic that is not otherwise
selected by a filter will go. This queue by default will have the name "Default". This name can
changed and another queue can be selected as the default. The default queue will be designated by
the asterisk "*" appended to the name.
CIR:
This is the Committed Information Rate of the queue. Setting this to a number higher than the
configured parent rate will result in an error.
MIR:
This is the Maximum Information Rate of the queue.
Prio:
This is the priority of the queue. Priorities range from 1 as the highest, to 8 as the lowest.
HC:
This indicates if Header Compression is enabled for the queue. If yes, it could be header or header
and payload. Only 31 queues can have HC enabled.
Warning Icon:
If a red exclamation icon appears in an object name, this indicates a
configuration warning. These warnings that the configuration will still
function but can't meet the specified criteria due to conflicting
parameters. If you hover over the icon, text will appear that advises of
the configuration conflict. The following messages are possible:

Too much CIR configured. Increase CIR for this object, or decrease CIR for the children

Too much CIR configured. Decrease CIR for this object, or increase CIR for the parent.

Too much MIR configured. Decrease MIR for this object, or increase MIR for the parent.
