VLAN:
Enter either 0 or a VLAN ID between 2 and 4094. Only one may be selected. 0 indicates untagged traffic as
the selection criteria. The default is * (any VLAN)
VLAN Priority:
Choose between 'any' or a priority value between 0 and 7. Only one choice may be selected. The default
is * (any VLAN priority)
MPLS Label:
If MPLS was selected as the protocol then a decimal value between 0 and 1048575 may be entered. If no
value is entered then all MPLS labels will match the filter criteria. If there are multiple MPLS labels, the
filter will only match the first label encountered in the packet.
MPLS experimental bits:
If MPLS was selected as the protocol then you can choose a value between 0 and 7 as match criteria. If '*'
is chosen then the filter does not use the experimental bits in the match criteria, otherwise all bits must
match exactly.
Destination Subnets:
This is specified in CIDR format. Multiple subnets may be separated by a comma. The default is '*' (any
subnet). Acceleration tunnels utilized by FX WAN Optimization may not maintain the original application
destination address, therefore this field should not be used when classifying FX WANOP traffic unless an
application policy is defined to prevent tunnel sharing between different destination subnets.
Destination Ports:
Port ranges can be specified by either entering the lowest port followed by '-', followed by highest port; or
multiple ports may be entered separated by comma. The destination port is relative to the FX.
Source Subnets:
This is specified in CIDR format. Multiple subnets may be separated by a comma. The default is '*' (any
subnet)
Source Ports:
Port ranges can be specified by either entering the lowest port followed by '-', followed by highest port; or
multiple ports may be entered separated by comma. The source port is relative to the FX. Acceleration
tunnels utilized by FX WAN Optimization do not maintain the original application source port; therefore
this field should not be used when classifying FX WANOP traffic.
NOTE: When specifying multiple fields as selection criteria the choices are logically "ANDed" when
formulating a match. Multiple selections within a field are logically "ORed" when formulating a
match.
