Monitors

WANOP Monitor
This Monitor provides a real time view of vital WANOP statistics for both the FX Series ADC
and the FX Series Remote.

QOS Monitors
The QoS Monitors provide a real time view of vital QoS statistics, including current, average
and elapsed stats. Monitors include one for Links and a second for Queues

1.5.3 Deployment Options

The FX Series ADC can run in single sided mode ADC only, in-line mode, routed mode or in WCCP mode.
The installation instructions for these are in the FX Series Installation Patterns Section.
