4.4

Universal Serial Bus (USB)

The conga-SEVAL provides the following USB connectors:
• Micro USB Type-AB
• Stacked Dual USB Type-A
– USB 2.0 (lower port)
– USB 3.0 (upper port)
• USB Type-C
The USB 2.0 signals are also routed to M.2 and mPCIe interfaces as shown below:
SMARC 2.0 Connector
Copyright © 2017 congatec AG
USB0 (2.0)
X2 - Micro USB AB
USB1 (2.0)
X3 - Dual Stacked
USB2 (3.0)
USB Type A
USB3 (2.0)
X4 - USB Type-C
USB4 (2.0)
X11 - M.2
USB5 (2.0)
X7 - miniPCIe
SEVALm10 30/58
