Table 55
Connector X62 Description
Pin
Signal
1
+V3.3
2
TDO
3
TDI
4
TCK
5
TMS
6
TEST#_EN (jumper X44)
7
GND
Connector Type
X62: 2.54 mm, 1x7 pin header
X44: 2.54 mm grid jumper
Copyright © 2017 congatec AG
JTAG for CGBC - X62
Pin 1
SEVALm10
56/58
