S/PDIF OUT
The conga-SEVAL provides S/PDIF-OUT signals on connector X20.
Table 35
SPDIF-OUT (Connector X20) Pinout Description
Pin Signal
A
GND
B
+V3.3S
C
HDA_SPDIFO
S1
NC
S2
NC
Connector Type
X20: TOSLINK optical audio output (JIS F05)
4.13
Display Interfaces
The conga-SEVAL provides the following display interfaces:
• Dual mode DisplayPort (DP++) on connector X33 (upper port)
• Native HDMI on connector X33 (lower port)
• DisplayPort alternate mode on USB Type C connector X4
• eDP / LVDS / DSI
– eDP on connector X31 or X32 or both
– LVDS / DSI on connector X23
