HDD Power Connector
The conga-SEVAL provides connector X58 for powering hard disks. Use this connector when operating in non-ATX mode.
Table 48
Connector X58 Description
Pin Signal
1
+12 V (1.5 A Fuse)
2
GND
3
GND
4
+5 V (2.0 A Fuse)
Connector Type
X58: 5.08 mm, 4-pin female connector
Copyright © 2017 congatec AG
HDD Power - X58
SEVALm10
50/58
