P-PIN Primary (Top) Side
P93 HDMI_D2- / DP1_LANE0-
P94 GND
P95 HDMI_D1+ / DP1_LANE1+
P96 HDMI_D1- / DP1_LANE1-
P97 GND
P98 HDMI_D0+ / DP1_LANE2+
P99 HDMI_D0- / DP1_LANE2-
P100 GND
P101 HDMI_CK+ / DP1_LANE3+
P102 HDMI_CK- / DP1_LANE3-
P103 GND
P104 HDMI_HPD / DP1_HPD
P105 HDMI_CTRL_CK / DP1_AUX+
P106 HDMI_CTRL_DAT / DP1_AUX-
P107 DP1_AUX_SEL
P108 GPIO0 / CAM0_PWR#
P109 GPIO1 / CAM1_PWR#
P110 GPIO2 / CAM0_RST#
P111 GPIO3 / CAM1_RST#
P112 GPIO4 / HDA_RST#
P113 GPIO5 / PWM_OUT
P114 GPIO6 / TACHIN
P115 GPIO7
P116 GPIO8
P117 GPIO9
P118 GPIO10
P119 GPIO11
P120 GND
P121 I2C_PM_CK
P122 I2C_PM_DAT
P123 BOOT_SEL0#
P124 BOOT_SEL1#
P125 BOOT_SEL2#
P126 RESET_OUT#
Copyright © 2017 congatec AG
S-Pin Secondary (Bottom) Side
S94 DP0_LANE0-
S95 DP0_AUX_SEL
S96 DP0_LANE1+
S97 DP0_LANE1-
S98 DP0_HPD
S99 DP0_LANE2+
S100 DP0_LANE2-
S101 GND
S102 DP0_LANE3+
S103 DP0_LANE3-
S104 USB3_OTG_ID
S105 DP0_AUX+
S106 DP0_AUX-
S107 LCD1_BKLT_EN
S108 LVDS1_CK+ / eDP1_AUX+ / DSI1_CLK+
S109 LVDS1_CK- / eDP1_AUX- / DSI1_CLK-
S110 GND
S111 LVDS1_0+ / eDP1_TX0+ / DSI1_D0+
S112 LVDS1_0- / eDP1_TX0- / DSI1_D0-
S113 eDP1_HPD
S114 LVDS1_1+ / eDP1_TX1+ / DSI1_D1+
S115 LVDS1_1- / eDP1_TX1- / DSI1_D1-
S116 LCD1_VDD_EN
S117 LVDS1_2+ / eDP1_TX2+ / DSI1_D2+
S118 LVDS1_2- / eDP1_TX2- / DSI1_D2-
S119 GND
S120 LVDS1_3+ / eDP1_TX3+ / DSI1_D3+
S121 LVDS1_3- / eDP1_TX3- / DSI1_D3-
S122 LCD1_BKLT_PWM
S123 RSVD
S124 GND
S125 LVDS0_0+ / eDP0_TX0+ / DSI0_D0+
S126 LVDS0_0- / eDP0_TX0- / DSI0_D0-
S127 LCD0_BKLT_EN
