Lvds / Dsi; Table 41 Connector X31 / X32 Pinout Description - Congatec SMARC 2.0 conga-SEVAL User Manual

12 eDP[0:1]_TX0-
13 eDP[0:1]_TX0+
14 GND
15 eDP[0:1]_AUX+
16 eDP[0:1]_AUX-
17 GND
18 VCC_EDP_FILT
19 VCC_EDP_FILT
20 VCC_EDP_FILT
Connector Type
X31, X32: 0.5mm , 40 Pos. ACES connector
4.13.4.2

LVDS / DSI

The conga-SEVAL supports a dual channel LVDS interface or a MIPI DSI interface on connector X23. To use connector X23 for LVDS display or
DSI display:
• the SMARC module must support LVDS or DSI signals
• set switch 2 of DIP switch M12 to OFF position
Table 41 Connector X31 / X32 Pinout Description
Dip Switch M12 Configuration
SW 1 SW 2
N.A ON eDP selection
N.A OFF LVDS / DSI selection
Copyright © 2017 congatec AG
32 eDP[0:1]_LVDS_BKLT_EN
33 eDP[0:1]_LVDS_BKLT_CTRL
34 N.C.
35 N.C.
36 N.C
37 BKLT_PWR
38 BKLT_PWR
39 BKLT_PWR
40 N.C.
M12
SEVALm10 46/58
