4.5.1
PCIe x4 Slot
The conga-SEVAL provides a PCIe x4 slot on connector X5. This slot supports only one PCIe lane by default. With BOM option, the connector
can support up to four PCIe lanes.
Connector Type
X5: PCIe x4 card
4.5.2
Mini PCIe
The conga-SEVAL provides a mini PCIe slot on connector X7.
Connector Type
X7: Mini PCIe card
4.5.3
PCIe x1 Slot
The conga-SEVAL provides a PCIe x1 slot on connector X9.
Connector Type
X9: PCIe x1 card
Copyright © 2017 congatec AG
PCIe x4 - X5
Mini PCIe - Connector X7
PCIe x1 - X9
SEVALm10
33/58
