5.6

Universal Serial Bus (USB)

The conga-IA4 provides 6 USB ports - 4 USB ports on the rear side and 2 USB ports internally. The USB routing diagram is shown below:
To mPCIe Connector
To mPCIe/mSATA Connector
Copyright © 2016 congatec AG
Intel Braswell SoC
USB HUB
1 2 3 4
1 2 3 4
2x USB 2.0 Rear Ports
(Connector X14)
conga-IA40 USB Connectors
2x USB 3.0/2.0 Internal Ports 2x USB 3.0/2.0 Rear Ports
(Connector X60) (Connector X15)
IA40m12.indd
9 8 7 6 5
1 2 3 4
9 8 7 6 5
1 2 3 4
