5.4

Debug Display Port

The conga-SEVAL provides four seven-segment displays for post code or debug information. The displays are connected to the general
purpose I2C bus. The default I2C address of the debug display is 0xE2.
Table 50 Jumper X56 Description
Pin Configuration
1-2 Enable postcode (default)
2-3 Disable postcode
Connector Type
X56: 2.54 mm grid jumper
5.5

GPIO

The conga-SEVAL provides 12 GPIOs (GPIO [0:11]). The GPIOs are available in different locations on the conga-SEVAL as shown in the table be
Table 51 GPIO Alternate Function and Routing
Signal Alternalte Function
GPIO0 CAM0_PWR#
GPIO1 CAM1_PWR#
GPIO2 CAM0_RST#
GPIO3 CAM1_RST#
GPIO4 HDA_RST#
GPIO5 PWM_OUT
GPIO6 TACHIN
GPIO[7:11] N.A
Copyright © 2017 congatec AG
Jumper X56
1 2 3
Routed To
GPIO connector X38, JTAG connector X62 or MIPI connector X13
GPIO connector X38, JTAG connector X62 or MIPI connector X13
GPIO connector X38, JTAG connector X62 or MIPI connector X13
GPIO connector X38, JTAG connector X62 or MIPI connector X13
Audio connector or feature connector X37
Fan connector X42 or feature connector X37
Fan connector X42 or feature connector X37
Feature connector X37
Debug Display
D55 D56 D57 D58
SEVALm10 54/58
