MIPI-CSI

The conga-SEVAL features a MIPI-CSI 2/3 flat foil connector (X13). The connector supports up to two camera interfaces—CSI0 and CSI1:
• CSI0 supports up to two differential data lanes
• CSI1 supports up to four differential data lanes
Table 27 Connector X13 Pinout Description
Pin Signal
1 +V3.3S
2 +V3.3S
3 CSI1_RX0+
4 CSI1_RX0-
5 GND
6 CSI1_RX1+
7 CSI1_RX1-
8 GND
9 CSI1_RX2+
10 CSI1_RX2-
11 CSI1_RX3+
12 CSI1_RX3-
13 GPIO3/CAM1_RST#
14 GND
15 CSI1_CLK+
16 CSI1_CLK
17 GND
18 CSI1_I2C_CLK
Connector Type
X13: 0.5 mm pitch, 36-pin flat foil connector
Copyright © 2017 congatec AG
Pin Signal
19 CSI1_I2C_DAT
20 GPIO1/CAM1_PWR#
21 CSI01_MCLK
22 GPIO0/CAM0_PWR#
23 CSI0_I2C_CLK
24 CSI0_I2C_DAT
25 GND
26 CSI0_CLK+
27 CSI0_CLK
28 GND
29 CSI0_RX0+
30 CSI0_RX0-
31 GPIO2/CAM0_RST#
32 CSI0_RX1+
33 CSI0_RX1-
34 GND
35 NC
36 NC
MIPI - Connector X13
