5.7

Universal Serial Bus (USB)

The conga-MEVAL provides the following USB connectors:
• one dual-stacked USB 3.1 Gen 2, Type-A (X3)
• three dual-stacked USB 2.0, Type-A (X4, X5 and X85)
• one USB Type B (CN1)
The COM Express USB signals are routed to the connectors as shown below:
Copyright © 2022 congatec GmbH
Port 0 (USB 3.1 Gen 2)
Port 1 (USB 3.1 Gen 2)
Port 2 (USB 2.0)
Port 3 (USB 2.0)
COM Express Connector
Port 7 (USB 2.0)
Port 4 (USB 2.0)
Port 5 (USB 2.0)
Port 6 (USB 2.0)
X3 - Dual Stacked
USB 3.1 Type A
X4 - Dual Stacked
USB 2.0 Type A
CN1 - USB Type B
X5 - LAN with Dual
USB 2.0 Type A
X15 - mini PCIe
X85 - Dual Stacked
USB 2.0 Type A
