Memory Riser Label
CM1/MR2
(Not on the 1-processor
server.)
CM1/MR3
(Not on the 1-processor
server.)
(Closest to power
supplies)
Related Information
"Memory Riser and DIMM Configuration" on page 99
"DIMM Rank Classification Labels" on page 100

Memory Riser and DIMM Configuration

The memory riser configuration rules for the server are as follows:
The 2-processor server contains eight memory risers. The 1-processor server contains four
memory risers. Four memory risers are supported per CPU.
Each of the memory riser slots in the server must be filled with a memory riser.
There are only two possible memory configurations: Fully populated and half populated.
DIMM configuration rules for each memory riser are as follows:
For a fully populated configuration, DIMMs must be installed in all four DIMM connectors
on each memory riser.
For a half populated configuration (with 16GB or 32GB DIMMs), DIMMs must be installed
in the two black DIMM connectors (labeled J701_ZA and J701_ZB) on each memory riser.
All memory risers must contain the same rank, size, and type of DIMM.
Memory Riser or DIMM FRU Name
/SYS/MB/CM1/CMP/MR1/BOB1/CH1/D0
/SYS/MB/CM1/CMP/MR2 (riser)
/SYS/MB/CM1/CMP/MR2/BOB0/CH0/D0
/SYS/MB/CM1/CMP/MR2/BOB0/CH1/D0
/SYS/MB/CM1/CMP/MR2/BOB1/CH0/D0
/SYS/MB/CM1/CMP/MR2/BOB1/CH1/D0
/SYS/MB/CM1/CMP/MR3 (riser)
/SYS/MB/CM1/CMP/MR3/BOB0/CH0/D0
/SYS/MB/CM1/CMP/MR3/BOB0/CH1/D0
/SYS/MB/CM1/CMP/MR3/BOB1/CH0/D0
/SYS/MB/CM1/CMP/MR3/BOB1/CH1/D0

Memory Riser and DIMM Configuration

Ejector
Color
White

Black
Black
White
White

Black
Black
White
White
Servicing Memory Risers and DIMMs
Slot Body
Color
White

Black
White
Black
White

Black
White
Black
White
99
